Farpointe Reader Specifications

Farpointe Reader Specifications

Specifications:

Size:

  1. P-300 - 1.7" W × 3.2" H × 0.7" D (43 mm × 81 mm × 18 mm)
  2. P-500 - 3" W × 4.6" H × 0.4" D (76 mm × 117 mm × 10 mm)
  3. P-700 - 8.5” H x 6” W x 0.83” T (21.6cm x 15.2cm x 2.1cm)
  4. P-640 - 4.6 x 3 x 0.7 inches (117 x 77 x 18 mm)

Weight:

  1. P-300 - 3oz (85 g)
  2. P-500 - 4 oz (113 g)
  3. P-700 - 1.3 lbs. (582g) (P-700)
  4. P-640 - 4 oz. (113 g)

Read Range*:

  1. P-300 - Up to 5 inches (126 mm)
  2. P-500 - Up to 6” (15cm) (P-500)
  3. P-700 - Up to 14” (35cm) (P-700)
  4. P-640:
    - PSC-1 - Up to 6 inches (152 mm)
    - PSM-2 - Up to 4 inches (102 mm)
    - PSI-4 - Up to 4 inches (102 mm)
    - PSK-3 - Up to 3 inches (76 mm)

Input Voltage:

  1. P-300 - +5 – 16 VDC
  2. P-500 - +12 VDC nom. (5-14 VDC) (P-500)
  3. P-700 - +11 VDC to +14 VDC (P-700)
  4. P-640 - +5 to 14 VDC

Current Draw:

  1. P-300 - 80 mA typical, 75 mA peak @ 12 VDC
  2. P-500 - 80 mA typical (P-500)
  3. P-700 - 285 mA typical (P-700)
  4. P-640 -  30 mA minimum, 50 mA typical, 115 mA peak

Operating Temperature:

  1. –40° F to 149° F (–40° C to +65° C)

LED Indicator:

  1. Tri-Color Standard (Red, Green, Amber)

Audio Tone:

  1. Standard Frequency: 125 KHz excitation, 62.5 KHz data return

Cabling Requirements

  1. 24 AWG minimum, multiconductor stranded with an overall foil shield - Belden 9536 (or equivalent)


Technologies Supported

  1. P-300/500/700: Pyramid Series Proximity® Cards and Tags
  2. P-300/500/700-H: Pyramid + certain HID® 125-kHz Proximity protocols
  3. P-300/500/700-A: Pyramid + certain AWID® 125-kHz Proximity protocols
  4. P-300/500/700-H-A: Pyramid + certain HID® 125-kHz Proximity protocols + certain AWID® 125-kHz Proximity protocols
(Supported HID credentials include, and may not be limited to, ProxCard II®, ISOProx® II, and ProxKey® II).

Installation Environment

Suitable for indoor and outdoor installation. The reader is sealed in a weather and tamper-resistant epoxy potting.

Warranty:

Lifetime warranty against defects in materials and workmanship.


* Read range is stated in a clean RF and electrical environment with KC-10X card presented parallel to reader surface.


Note: Specifications subject to change without notice. Trademarks are the property of their respective owners.
